📋 Basic Information
Charging Interfaces
Multiple Charges
Installation
Wall/Floor Mounted
Charge Method
Quick Charge
Screen
7 Inch Touch Screen
⚡ Product Description
📊 Product Parameters
| Electrical Specifications |
Input: 400Vac 3-phase | Frequency: 50Hz/60Hz | Power: 60kW/120KW DC |
| Output Range |
CCS: 200-1000VDC (200A) | CHAdeMO: 200-500VDC (125A) |
| Structure |
Metal Case | 1900 x 725 x 700mm | Floor-stand | 380kgs |
| Communication |
PLC, CAN, Wifi, 3G/4G, OCPP 1.6 |
| Environment |
Temp: -30°C to +55°C | IP54 | Fan Cooling |
| Security |
Over/Under voltage, Overload, Leakage, Grounding, Temp protection |
🏭 Company & Logistics
❓ Frequently Asked Questions
Why choose us as your preferred EV Charger supplier?
We offer a professional technical team with a long-term industry vision. Our products meet international standardization designs and have passed rigorous laboratory tests. We are among the few vendors capable of providing both CE and UL certified DC chargers.
Do you have experience in overseas charging projects?
Yes, we are pioneers in global projects, including PV-integrated systems in the UK, highway fast-charging networks in the US (LA to San Francisco), and automaker fleet services.
What are the advantages of your EV chargers?
Our products feature telecom-level design, support multiple standards (CCS-1/2, CHAdeMO, GB/T), and offer wide input/output voltage ranges with advanced modular design for better reliability.
What are the differences between global DC fast charging standards?
There are 5 main standards: CCS-1 (North America), CCS-2 (Europe), CHAdeMO (Japan), GB/T (China), and Tesla. We provide solutions compatible with these global requirements.
Does higher output power always mean faster charging?
Not necessarily, as it depends on the vehicle's battery limit. However, high-power chargers support dual-connector simultaneous charging and provide future-proofing as battery technology improves.
How is after-sales support handled for international customers?
We provide comprehensive technical training through manuals and videos. For urgent situations, we offer professional technical support to assist with maintenance and parts replacement.
